Pulmonary artery catheter hemodynamics
Simplified Fick · Estimated VO₂
mPAP: Unavailable
Adult resting references are not treatment targets. Context-dependent indices have no universal reference label.
Needs valid Hemoglobin, Arterial saturation, PA saturation, Height, Weight
Entered CO, or VO2 / [1.36 × Hb × (SaO2 − SvO2)] × 10; saturations in percent
Simplified Fick omits dissolved oxygen. Blank measured VO2 uses 125 × BSA mL/min, so CO remains estimated. Entered CO takes precedence.
Edwards: adult resting reference valuesACC: hemodynamic assessment and Fick limitationsNeeds valid Hemoglobin, Arterial saturation, PA saturation, Height, Weight
CO / BSA
Adult resting reference, not a treatment target or severity score. Interpret with measurement quality and clinical context.
Edwards: adult resting reference valuesACC: hemodynamic assessment and Fick limitationsNeeds valid Hemoglobin, Arterial saturation, PA saturation, Height, Weight, Heart rate
1000 × CO / HR
Adult resting reference, not a treatment target or severity score. Interpret with measurement quality and clinical context.
Edwards: adult resting reference valuesNeeds valid Hemoglobin, Arterial saturation, PA saturation, Height, Weight, Heart rate
SV / BSA
Adult resting reference, not a treatment target or severity score. Interpret with measurement quality and clinical context.
Edwards: adult resting reference valuesNeeds valid Systemic SBP, Systemic DBP
Measured MAP, otherwise (SBP + 2 × DBP) / 3
Adult resting reference, not a treatment target or severity score. Interpret with measurement quality and clinical context.
Edwards: adult resting reference valuesNeeds valid Height, Weight
sqrt(height (cm) × weight (kg) / 3600), Mosteller
Adult resting reference, not a treatment target or severity score. Interpret with measurement quality and clinical context.
Edwards: adult resting reference valuesNeeds valid Systemic SBP, Systemic DBP, Hemoglobin, Arterial saturation, PA saturation, Height, Weight
MAP × CO / 451
No universal adult reference interval is applied here. Published risk thresholds depend on the population and clinical setting; this value alone is not a diagnosis.
Edwards: adult resting reference valuesNeeds valid Systemic SBP, Systemic DBP, Hemoglobin, Arterial saturation, PA saturation, Height, Weight
MAP × CI / 451
Adult resting reference, not a treatment target or severity score. Interpret with measurement quality and clinical context.
Edwards: adult resting reference valuesNeeds valid Systemic SBP, Systemic DBP, Hemoglobin, Arterial saturation, PA saturation, Height, Weight, Heart rate, PCWP
SVI × (MAP − PCWP) × 0.0136
Adult resting reference, not a treatment target or severity score. Interpret with measurement quality and clinical context.
Edwards: adult resting reference valuesNeeds valid PA systolic, PA diastolic, Hemoglobin, Arterial saturation, PA saturation, Height, Weight, Heart rate, RA / CVP
SVI × (mPAP − RA) × 0.0136
Adult resting reference, not a treatment target or severity score. Interpret with measurement quality and clinical context.
Edwards: adult resting reference valuesNeeds valid Systemic SBP, Systemic DBP, Hemoglobin, Arterial saturation, PA saturation, Height, Weight, RA / CVP
80 × (MAP − RA) / CO
Adult resting reference, not a treatment target or severity score. Interpret with measurement quality and clinical context.
Edwards: adult resting reference valuesNeeds valid Systemic SBP, Systemic DBP, Hemoglobin, Arterial saturation, PA saturation, Height, Weight, RA / CVP
80 × (MAP − RA) / CI
Adult resting reference, not a treatment target or severity score. Interpret with measurement quality and clinical context.
Edwards: adult resting reference valuesNeeds valid PA systolic, PA diastolic, Hemoglobin, Arterial saturation, PA saturation, Height, Weight, PCWP
(mPAP − PCWP) / CO
Adult resting reference, not a treatment target or severity score. Interpret with measurement quality and clinical context.
Diagnostic context: PH is defined by mPAP >20 mmHg at rest; pre-capillary PH additionally requires PAWP ≤15 mmHg and PVR >2 WU. This is not a severity scale.
2022 ESC/ERS pulmonary hypertension guidelinesNeeds valid PA systolic, PA diastolic, Hemoglobin, Arterial saturation, PA saturation, Height, Weight, PCWP
(mPAP − PCWP) / CI
No universal adult reference interval is applied here. Published risk thresholds depend on the population and clinical setting; this value alone is not a diagnosis.
2022 ESC/ERS pulmonary hypertension guidelinesNeeds valid PA systolic, PA diastolic
Measured mPAP, otherwise (PAs + 2 × PAd) / 3
Adult resting reference, not a treatment target or severity score. Interpret with measurement quality and clinical context.
Diagnostic context: PH is defined by mPAP >20 mmHg at rest; pre-capillary PH additionally requires PAWP ≤15 mmHg and PVR >2 WU. This is not a severity scale.
2022 ESC/ERS pulmonary hypertension guidelinesNeeds valid PA systolic, PA diastolic, RA / CVP
(PAs − PAd) / RA
No universal adult reference interval is applied here. Published risk thresholds depend on the population and clinical setting; this value alone is not a diagnosis.
Edwards: adult resting reference valuesNeeds valid RA / CVP, PCWP
RA / PCWP
No universal adult reference interval is applied here. Published risk thresholds depend on the population and clinical setting; this value alone is not a diagnosis.
Edwards: adult resting reference valuesNeeds valid Hemoglobin, Arterial saturation, PA saturation, Height, Weight, Heart rate, PA systolic, PA diastolic
SV / (PAs − PAd)
No universal adult reference interval is applied here. Published risk thresholds depend on the population and clinical setting; this value alone is not a diagnosis.
2022 ESC/ERS pulmonary hypertension guidelinesNeeds valid PA systolic, PA diastolic, PCWP
mPAP − PCWP
No universal adult reference interval is applied here. Published risk thresholds depend on the population and clinical setting; this value alone is not a diagnosis.
2022 ESC/ERS pulmonary hypertension guidelinesNeeds valid PA diastolic, PCWP
PAd − PCWP
No universal adult reference interval is applied here. Published risk thresholds depend on the population and clinical setting; this value alone is not a diagnosis.
2022 ESC/ERS pulmonary hypertension guidelinesNeeds valid Hemoglobin, Arterial saturation, PA saturation, Height, Weight
CO × CaO2 × 10
Estimated from hemoglobin-bound oxygen only; dissolved oxygen is omitted. In shunt mode, CvO2 uses the pre-shunt sample.
Edwards: adult resting reference valuesNeeds valid Hemoglobin, Arterial saturation
1.36 × Hb × SaO2 / 100
Estimated from hemoglobin-bound oxygen only; dissolved oxygen is omitted. In shunt mode, CvO2 uses the pre-shunt sample.
Edwards: adult resting reference valuesNeeds valid Hemoglobin, PA saturation
1.36 × Hb × SvO2 / 100
Estimated from hemoglobin-bound oxygen only; dissolved oxygen is omitted. In shunt mode, CvO2 uses the pre-shunt sample.
Edwards: adult resting reference valuesNeeds valid Hemoglobin, Arterial saturation, PA saturation
100 × (CaO2 − CvO2) / CaO2
Estimated from hemoglobin-bound oxygen only; dissolved oxygen is omitted. In shunt mode, CvO2 uses the pre-shunt sample.
Edwards: adult resting reference values
